Nebula LiveJournal, Import LiveJournal Dataset into Nebula Graph and Run Nebula Algorithm

一个导入 Livejournal 数据集到 Nebula Graph 图数据库,并执行 Nebula Algorithm 图算法的过程分享。

Related GitHub Repo: https://github.com/wey-gu/nebula-LiveJournal

nebula-LiveJournal

LiveJournal Dataset is a Social Network Dataset in one file with two columns(FromNodeId, ToNodeId).

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
$ head soc-LiveJournal1.txt
# Directed graph (each unordered pair of nodes is saved once): soc-LiveJournal1.txt
# Directed LiveJournal friednship social network
# Nodes: 4847571 Edges: 68993773
# FromNodeId	ToNodeId
0	1
0	2
0	3
0	4
0	5
0	6

It could be accessed in https://snap.stanford.edu/data/soc-LiveJournal1.html.

Dataset statistics
Nodes 4847571
Edges 68993773
Nodes in largest WCC 4843953 (0.999)
Edges in largest WCC 68983820 (1.000)
Nodes in largest SCC 3828682 (0.790)
Edges in largest SCC 65825429 (0.954)
Average clustering coefficient 0.2742
Number of triangles 285730264
Fraction of closed triangles 0.04266
Diameter (longest shortest path) 16
90-percentile effective diameter 6.5

Dataset Download and Preprocessing

Download

It is accesissiable from the official web page:

1
2
$ cd nebula-livejournal/data
$ wget https://snap.stanford.edu/data/soc-LiveJournal1.txt.gz

Comments in data file should be removed to make the data import tool happy.

Preprocessing

1
2
$ gzip -d soc-LiveJournal1.txt.gz
$ sed -i '1,4d' soc-LiveJournal1.txt

Import dataset to Nebula Graph

With Nebula Importer

Nebula-Importer is a Golang Headless import tool for Nebula Graph.

You may need to edit the config file under nebula-importer/importer.yaml on Nebula Graph’s address and credential。

Then, Nebula-Importer could be called in Docker as follow:

1
2
3
4
5
6
7
8
$ cd nebula-livejournal

$ docker run --rm -ti \
    --network=nebula-net \
    -v nebula-importer/importer.yaml:/root/importer.yaml \
    -v data/:/root \
    vesoft/nebula-importer:v2 \
    --config /root/importer.yaml

Or if you have the binary nebula-importer locally:

1
2
$ cd data
$ <path_to_nebula-importer_binary> --config ../nebula-importer/importer.yaml

With Nebula Exchange

Nebula-Exchange is a Spark Application to enable batch and streaming data import from multiple data sources to Nebula Graph.

To be done. (You can refer to https://siwei.io/nebula-exchange-sst-2.x/)

Run Algorithms with Nebula Graph

Nebula-Algorithm is a Spark/GraphX Application to run Graph Algorithms with data consumed from files or a Nebula Graph Cluster.

Supported Algorithms for now:

Name Use Case
PageRank page ranking, important node digging
Louvain community digging, hierarchical clustering
KCore community detection, financial risk control
LabelPropagation community detection, consultation propagation, advertising recommendation
ConnectedComponent community detection, isolated island detection
StronglyConnectedComponent community detection
ShortestPath path plan, network plan
TriangleCount network structure analysis
BetweennessCentrality important node digging, node influence calculation
DegreeStatic graph structure analysis

Ad-hoc Spark Env setup

Here I assume the Nebula Graph was bootstraped with Nebula-Up, thus nebula is running in a Docker Network named nebula-docker-compose_nebula-net.

Then let’s start a single server spark:

1
2
3
4
docker run --name spark-master --network nebula-docker-compose_nebula-net \
    -h spark-master -e ENABLE_INIT_DAEMON=false -d \
    -v nebula-algorithm/:/root \
    bde2020/spark-master:2.4.5-hadoop2.7

Thus we could make spark application submt inside this container:

1
2
3
4
docker exec -it spark-master bash
cd /root/
# download Nebula-Algorithm Jar Packagem, 2.0.0 for example, for other versions, refer to nebula-algorithm github repo and documentations.
wget https://repo1.maven.org/maven2/com/vesoft/nebula-algorithm/2.0.0/nebula-algorithm-2.0.0.jar

Run Algorithms

There are many altorithms supported by Nebula-Algorithm, here some of their configuration files were put under nebula-algorithm as an example.

Before using them, please first edit and change Nebula Graph Cluster Addresses and credentials.

1
vim nebula-altorithm/algo-pagerank.conf

Then we could enter the spark container and call corresponding algorithms as follow.

Please adjust your --driver-memeory accordingly, i.e. pagerank altorithm:

1
2
3
4
/spark/bin/spark-submit --master "local" --conf spark.rpc.askTimeout=6000s \
    --class com.vesoft.nebula.algorithm.Main \
    --driver-memory 16g nebula-algorithm-2.0.0.jar \
    -p pagerank.conf

After the algorithm finished, the output will be under the path insdie the container defined in conf file:

1
2
3
    write:{
        resultPath:/output/
    }
